Cytotoxic activity of crude saponins from Gaultheria trichophylla against human breast cancer cells MCF-7 and MDA-MB-468

  • Fiaz Alam Department of Pharmacy, COMSATS Institute of Information Technology, Abbottabad, Pakistan
  • Qazi Najam us Saqib Department of Pharmacy, COMSATS Institute of Information Technology, Abbottabad, Pakistan;
  • Abdul Waheed Wolfson Cell Science Centre, Faculty of Health & Medical Sciences, University of Surrey, Guildford, UK.
Keywords: Apoptosis, Breast cancer, DAPI, G. trichophylla, MTT, NRU
DOI: 10.3329/bjp.v10i2.22992


This study was conducted to evaluate Gaultheria trichophylla crude extract and respective saponins fraction against human breast cancer cell lines. In MTT assay, cell viability was inhibited by G. trichophylla crude extract (500 µg/mL) and saponins (200 µg/mL) in a dose dependent manner with maximum inhibition of (82 and 85%) and (71 and 42%) against MCF-7 and MDA MB-468, respectively. In neutral red uptake assay, the cell viability was inhibited by crude extract and saponins (100 µg/mL) in a similar manner with maximum inhibitions of (96 and 93%) and (87 and 61%) against MCF-7 and MDA MB-468, respectively, with respect to 91 and 93% inhibition by actinomycin-D (4 µM). The DAPI (4',6-diamidino-2-phenylindole) (10 µg/mL) staining of MCF-7 cells treated with crude saponins showed shrunken nuclei with apparent nuclear fragmentation indicating apoptosis and in contrast, MDA MB-468 showed necrosis mode of cell death. The study exhibited that the G. trichophylla provides new evidences to further explore this plant for the novel targets in anticancer drug development.


With more than 10 million new cases every year, cancer has become one of the most devastating diseases worldwide. Natural products have been the source of most of the active ingredients of medicines. According to a report half of the drugs approved since 1994 are based on natural products. Thirteen natural-product- related drugs were approved from 2005 to 2007. They cover a range of therapeutic indications, mainly the anticancer (Cragg et al., 1997). It is well known that in the past some medicinally important plants like Catharanthus roseus, Podophyllum peltatum and Taxus brevifolia and others provided therapeutically active metabolites which were used to control the advance stages of malignancies (Farnsworth and Soejarto, 1991). Therefore, as always, there is need to find alternative drugs with low toxicity, more effective and accessible to common man. Therefore, the present study was carried out to investigate the anticancer activity of extract and crude saponins fraction from Gaultheria trichophylla in cultured MCF-7 and MDA MB-468 human breast cancer cells.

trichophylla Royle (Family Ericaceae) is native to the Himalayas and therefore common name is Himalayan Snowberry. Plants belonging to genus Gaultheria like G. yunnanensis, G. fragrantissima and G. Procumbens are reported to have anti-inflammatory activity, antibacterial activity, and is used to treat arthritis. Gaultherin a natural salicylate isolated from G. yunnanensis possesses analgesic and anti-inflammatory activities. The phytochemical investigation of the species investigated reported to contain methyl salicylate, diterpenoids, acids, dilactone, alkaloids and other glycosides. Cytotoxic activities against the selected cancer cell lines are also reported in plants like G. itoana and G. yunnanensis (Liu et al., 2013).

Materials and Methods


Neutral red solution, fetal bovine serum (FBS), actinomycin-D, Dulbecco’s modified Eagle medium (DMEM) and 4,6-diamidineo-2-phenylinldole (DAPI) were obtained from Sigma Chemical Co. (St Lois, MO, USA). MCF-7 and MDA-MB-468 cells were purchased from ATCC (American Type Culture Collection, USA) through an authorized distributor, LGC Standards, Teddington, UK.

Plant material

G. trichophylla plant (5 kg) was collected by the author from Kaghan valley, District Mansehra, KPK, Pakistan, in November, 2013. After authentication of the plant, its voucher specimen (CTPHM-GT01, 13) was deposited in the herbarium of the Department of Pharmacy, the COMSATS Institute of Information Technology, Abbottabad. The whole plant was washed under running water and dried in shade at room temperature and was ground to a coarse powder. The powder drug was stored in air tight and light resistant container before extraction.

Preparation of extract and crude saponins

The dried, powdered plant material (200 g) was extracted with methanol using soxhlet extractor for 20 hours. It was filtered through a Whatman Grade-I filter paper. The filtrate was evaporated on a vacuum rotary evaporator under reduced pressure at 40°C. Extracted percent yield of the methanol fraction (G. Me) was 21.9%. For the extraction of saponins from powdered materials (200 g) of whole plant of G. trichophylla, was extracted first with petroleum ether, and followed by extraction with methanol in soxhlet apparatus. The solvent was reduced on a rotary evaporator under vacuum to obtain dry semisolid extract. The methanol extract of the plant was further fractionated with n-butanol and water, in equal proportion. The n-butanol fraction was separated.  The crude saponins were precipitated with petroleum ether; yield was approximately 4.5 g of crude saponins (G. Sa) (Dande et al., 2010).

Cell culture

Cells were grown in complete growth medium: Dulbecco’s modified Eagle medium (DMEM) containing 10% v/v FBS, 2 mM L-glutamine, gentamicin (40 μg/mL), penicillin (100 units/mL) and streptomycin (1040 μg/mL). Cells were seeded into 96-well cell culture plates at a density of 1 x 104 cells per well in 100 μL aliquots of the medium.  The cells were allowed to attach for 24 hours at 37°C, 5% CO2 in air in a humidified atmosphere in an incubator.

Preparation of the drug for the experiment

Crude extract of G. trichophylla was tested for cell cytotoxicity against breast cancer cell lines. A series of eight dilutions (10, 25, 50, 100, 200, 300, 400 and 500 μg of final concentration) of crude extract were prepared in DMEM (100 μL) containing DMSO (dimethyl sulfoxide, maximum: 0.01%). After the preliminary screening results a test dose of 200 μg for MTT (methyl-thiazolyltertrazolium) assay and 100 μg for NRU (neutral red uptake) assay was set for G. Sa based on apparent IC50 of G. Me.

Cytotoxicity assays

After a 24 hours exposure test period, the toxic end-points were determined using two colorimetric assays; namely the MTT assay and neutral red uptake (NRU) assay.

MTT assay

According to the method described elsewhere (Borenfreund et al., 1988; Green and Kroemer, 2004; Qadir et al., 2014) growth of cancer cells was quantified. Following a 24 hours exposure test period of drugs, cells were washed twice with phosphate buffer saline (PBS), and a 10 μL of MTT reagent (5 mg/mL in PBS) was added to each well including the blanks, which contained medium only. The plates were returned to the incubator for 4 hours at 37°C. Subsequently, cells were washed twice with PBS, and 100 µL/well DMSO was added in each well as solvent to dissolve the insoluble crystalline formazan products. The effect of plant extracts on cancer cells was quantified as the percentage of control absorbance of reduced dye at 550 nm on a microplate reader (LabtechLT-4000MS, Labtechm International Ltd., East Sussex, and UK). For each treatment, five replicates wells were examined, and each experiment was repeated three times. Standard error of mean was calculated between three experiments. The results were calculated as percentage growth inhibition, untreated (control) cells versus treated cells according to the following formula:

%Growth inhibition = {(Control-actual absorbance)/Control } x 100

Absorbance of the media was subtracted, both from control and treated cells.

NRU assay

The neutral red uptake assay was performed according to the method of (Borenfreund and Puerner, 1985) by removal of the medium after dosing cells and 200 μL of neutral red solution (40 μg/mL) was added to each well (including the blanks, which contained medium only).  After incubation for two and half hours, the neutral red was removed, cells were carefully rinsed with pre-warmed PBS, and 200 μL of ethanol/acetic acid (1% glacial acetic acid in 5% ethanol) was added to all wells.

The plates were covered in foil and placed on a plate shaker for 30 min to extract neutral red dye from the cells to form a homogeneous solution. Absorbance of the wells was measured at 540 nm in a microplate reader within 60 min. For each treatment, five replicates wells were examined and each experiment was repeated three times. The results were calculated as percentage growth inhibition, untreated (control) cells versus treated cells, according to the formula as described previously for MTT assay. Standard error means were calculated between three experiments.

Cytomorphological alterations (DAPI staining)

In the present study, DAPI (4',6-diamidino-2-phenylindole) stain was used to assess the morphological changes in nuclei of control and treated cells. Cells were seeded at density of 1 x 104 cells/well in 500 μL of medium on sterilized glass cover slips in well plates for 24 hours.  The cells were treated with the negative control (culture medium) and the positive control (actinomycin-D, 4 μM). The plates were incubated at 37°C, 5% CO2 in air in a humidified atmosphere for 24 hours.  After treatment, cells were briefly equilibrated with PBS, fixed with 4% paraformaldehyde for 15 min, permeabilized with methanol for 5 min, and mounted in a DAPI-containing medium (Vector Shield, Vector Labs, Peterborough, UK). The morphology of the nuclei was observed using a confocal fluorescence microscope, Leica SP2 AOBS confocal microscope (Leica Microsystems, Mannheim, Germany) with excitation at 350 nm and emission 460 nm under a x40  oil objective (Saha et al., 2013).

Data presentation and statistical analysis

All data were compiled from a minimum of three experiments. Data for statistical analysis were expressed as the mean ± SEM. One-way ANOVA with Dunnett’s test, as specified, was performed using GraphPad Prism version 6.00 for Windows, GraphPad Software, San Diego California, USA.


The results from the MTT and NRU assays of cellular viability in various concentrations of methanolic crude extract (G.Me) of G. trichophylla are listed in Table I. MCF-7 and MDA MB-468 cells were inhibited by crude extract with a rate increasing with increasing concentration. The inhibition rate of G. Me (500 μg/mL) against MCF-7 and MDA MB-468 cells was about 82 and 85% respectively in MTT assay. The inhibition rate of G. Me (500 μg/mL) against MCF-7 and MDA MB-468 cells was about 96 and 93% respectively in the NRU assay (Table I).

Table I:Dose-dependent growth inhibition of cancer cell lines by crude extract of Gaultheria trichophylla

Concentration (µg/mL) MTT assay NRU assay
%Growth inhibition %Growth inhibition
MCF-7 cells MDA MB-468 cells MCF-7 cells MDA MB-468 cells
10 22.1 ± 5.9a 9.4 ± 4.9 29.0 ± 6.1a 30.1 ± 3.2b
25 24.7 ± 7.1a 15.8 ± 5.4a 33.0 ± 5.3b 43.9 ± 3.4b
50 41.6 ± 3.8b 38.4 ± 6.3b 44.1 ± 3.6b 46.0 ± 4.2b
100 40.0 ± 3.4b 46.2 ± 1.8b 50.7 ± 4.2c 53.3 ± 3.4c
200 48.4 ± 4.2b 61.6 ± 7.3c 51.5 ± 5.1c 52.6 ± 3.9c
300 67.6 ± 3.0c 70.0 ± 4.7c 58.0 ± 3.2c 73.7 ± 4.0c
400 70.0 ± 6.5c 74.8 ± 3.7c 81.6 ± 6.3c 87.2 ± 6.4c
500 82.3 ± 3.9c 85.0 ± 6.4c 96.1 ± 7.0c 93.8 ± 7.3c
Vehicle control 1.1 ± 4.4 -1.6 ± 5.2 -1.6 ± 6.1 4.0 ± 3.0

The inhibition of crude saponins of G. trichophylla (G. Sa) against MCF-7 and MDA MB-468 cancer cell lines were tested in dose of 200 μg/mL for MTT assays and in dose of 100 μg/mL for NRU assay. In MTT assay the saponins inhibited the growth of MCF-7 and MDA MB-468 by about 71 and 42%, respectively, with respect to actinomycin-D (4 µM) which showed the growth inhibition of about 62%. The response to G. Sa was more pronounced in NRU assay, and a growth inhibition of about 87 and 61% was observed against MCF-7 and MDA MB-468, respectively, with respect to actinomycin-D (4 µM) which showed the growth inhibition of 91 and 93%, respectively (Table II and III).

Table II: Cytotoxic activity of saponins fractions from Gaultheria trichophylla using MTT assay

Experiment Absorbance
(cells + fraction + media)
Actual absorbance
(cells + fraction + media)
% Growth inhibition (mean ± SD)
1 2 3 1 2 3 100
Saponins fraction (200 µg/mL)
Media 0.1 0.1 0.1 0.0 0.0 0.0 -
Media + Cells 0.1 0.1 0.1 0.1 0.1 0.09 -
MCF-7 cells 0.1 0.1 0.1 0.0 0.0 0.02 71.5 ± 3.7
MDA MB-468 0.1 0.1 0.1 0.1 0.1 0.05 42.6 ± 4.4
Vehicle Control 0.1 0.1 0.1 0.1 0.1 0.08 2.8 ± 3.1
Actinomycin-D (4 µM)
MCF-7 cells 1.2 1.2 1.1 0.9 1.0 0.9 62.0 ± 1.4
MDA MB-468 1.5 1.5 1.5 1.0 0.8 0.7 62.8 ± 5.3
Vehicle Control 0.3 0.3 0.2 0.1 0.1 0.0 1.1 ± 1.1

Table III:Cytotoxic activity of saponins fractions from Gaultheria trichophylla using NRU assay

Experiment Absorbance
(cells + fraction + media)
Actual absorbance
(cells + fraction + media)
% Growth inhibition (mean ± SD)
1 2 3 1 2 3 100
Saponins fraction (100 µg/mL)
Media 0.1 0.1 0.1 0.0 0.0 0.0 -
Media + Cells 0.2 0.2 0.2 0.1 0.1 0.1 -
MCF-7 cells 0.1 0.1 0.1 0.0 0.0 0.0 87.2 ± 2.8
MDA MB-468 0.1 0.1 0.1 0.0 0.0 0.0 61.4 ± 14.8
Vehicle Control 0.2 0.2 0.2 0.1 0.1 0.1 -2.01 ± 4.7
Actinomycin-D (4 µM)
MCF-7 cells 0.2 0.2 0.2 0.0 0.0 0.0 91.8 ± 3.7
MDA MB-468 0.5 0.6 0.6 0.0 0.0 0.0 93.9 ± 5.0
Vehicle Control 0.3 0.3 0.3 0.1 0.1 0.1 1.6 ± 1.0

Both the untreated (control) and G. Sa (10 µg/mL) treated cells were stained with DAPI and visualized by confocal microscope (Figure 1). The control cells of MCF-7 were found with normal morphology and intact nuclei, while the treated cells were exhibiting the apoptotic characteristics, with condensed and fragmented nuclei, along with marked shrinkage in the cell membranes. This was a clear indication of apoptosis induced in MCF-7 cancer cells. DAPI staining of G. Sa treated MDA MB-468 cells showed necrotic cells characterized by swelling and increasing in size before the disruption.

Figure 1: Morphological assessment of control (A and B) and Gaultheria trichophylla saponins (G. Sa) (10 µg/mL, final concentration) treated MCF-7 cells (A2) and MDA MB-468 (B2) for 24 hours. The nuclei were stained with DAPI and observed under confocal microscope


In the recent past, there has been unforeseen interest in the clinical utilization of saponins as chemotherapeutic agents and over 400 studies have been reported regarding the saponins and their ability to treat cancer or induce apoptosis. It is reported that saponins exert its cytotoxic activity through apoptosis through signaling pathways to prevent the tumor. Numerous steroid and triterpenoid saponins exhibit cytotoxic properties (Thakur et al., 2011). The plants of genus Gaultheria have been reported to suppress the malignant neoplastic cells (Li et al., 2010). Our previous study also showed that the crude saponins caused the inhibition of  colon cancer cells lines through mechanism involving apoptosis (Alam et al., 2015). MTT assay is used to determine viable cell number in cytotoxicity studies. Mitochondrial dehydrogenase produced by normal cells reduce MTT (Yellow) to blue formazan product, which reflects the normal function of mitochondria and cell viability (Lau et al., 2004).  MTT assay results showed that G. Me and G. Sa showed dose dependent antiproliferative activity and is effective in inhibiting the growth of MCF-7 and MDA MB-468 cells. The neutral red (NR) metabolic impairment assay also showed that G. Me and G. Sa inhibited the growth of MCF-7 and MDA MB-468 cells.

Apoptosis is a programmed cell death process that occurs in physiological and pathological conditions and a defect in apoptotic pathways has an important role in carcinogenesis. It is characterized by cell shrinkage, chromatin condensation, DNA fragmentation and formation of apoptotic bodies. The induction of apoptosis for the prevention of cancer is therefore desirable. Necrotic cell death, in contrast, is characterized by the loss of metabolic functions, and of the integrity of the cell membrane. Structurally, the cells’ organelles swell and become nonfunctional during the initial stages of necrosis (Nanji and Hiller-Sturmhöfel, 1997). DAPI staining is most commonly used assay for observing the apoptosis at the DNA level (Saha et al., 2013). In this study G. Sa induced morphological changes in apoptotic cells, which were observed in DAPI staining of MCF-7 cells.


This study demonstrates that the treatment with G. Sa resulted in the apoptotic body formation, chromatin condensation and nuclear fragmentation. It clearly shows the potential of G. Sa to induce apoptosis against MCF-7 cancer cell lines. While, on the other hand DAPI staining of MDA MB-468 cells indicated necrosis mode of cell death.


Alam F, Saqib QN, Waheed A. Effect of crude saponins from Gaultheria trichophylla extract on growth inhibition in human colorectal cancer cells. Bangladesh J Pharmacol. 2015; 10: 160-65.

Borenfreund E, Babich H, Martin-Alguacil N. Comparisons of two in vitro cytotoxicity assays: The neutral red (NR) and tetrazolium MTT tests. Toxicol In vitro. 1988; 2: 1-6.

Borenfreund E, Puerner JA. Toxicity determined in vitro by morphological alterations and neutral red absorption. Toxicol Lett. 1985; 24: 119-24.

Cassileth BR, Chapman CC. Alternative and complementary cancer therapies. Cancer 1996; 77: 1026-34.

Cragg GM, Newman DJ, Snader KM. Natural products in drug discovery and development. J Nat Prod. 1997; 60: 52-60.

Dande PR, Talekar VS, Chakraborthy G. Evaluation of crude saponins extract from leaves of Sesbania sesban (L.) Merr. for topical anti-inflammatory activity. Int J Res Pharm Sci. 2010; 1: 296-99.

Farnsworth NR, Soejarto D. Global importance of medicinal plants. The conservation of medicinal plants. 1991, pp 25-51.

Green DR, Kroemer G. The pathophysiology of mitochondrial cell death. Science 2004; 305: 626-29.

Lau C, Ho C, Kim C, Leung K, Fung K, Tse T, et al. Cytotoxic activities of Coriolus versicolor (Yunzhi) extract on human leukemia and lymphoma cells by induction of apoptosis. Life Sci. 2004; 75: 797-808.

Li J, Li F, Lu YY, Su XJ, Huang CP, Lu XW. A new dilactone from the seeds of Gaultheria yunnanensis. Fitoterapia 2010; 81: 35-37.

Liu WR, Qiao WL, Liu ZZ, Wang XH, Jiang R, Li SY, et al. Gaultheria: Phytochemical and pharmacological characteristics. Molecules 2013; 18: 12071-108.

Nanji AA, Hiller-Sturmhöfel S. Apoptosis and necrosis. Alcohol Health Res World. 1997; 21: 325-30.

Qadir MI, Ali M, Ibrahim Z. Anticancer activity of Morus nigra leaves extract. Bangladesh J Pharmacol. 2014; 9: 496-97.

Saha SK, Sikdar S, Mukherjee A, Bhadra K, Boujedaini N, Khuda-Bukhsh AR. Ethanolic extract of the Goldenseal, Hydrastis canadensis, has demonstrable chemopreventive effects on HeLa cells in vitro: Drug–DNA interaction with calf thymus DNA as target. Env Toxicol Pharmacol. 2013; 36: 202-14.

Thakur M, Melzig MF, Fuchs H, Weng A. Chemistry and pharmacology of saponins: Special focus on cytotoxic properties. Botanics Targets Therapy. 2011; 1: 19-29.
